FIAT E-DOBLO L1

100kW 52kWh H1 Van Primo Auto

FIAT E-DOBLO L1 100kW 52kWh H1 Van Primo Auto

Vehicle Information

Fuel Type Electric
Transmission Automatic
Top Speed 82mph
CO2 0.00g/km
Range (WLTP): 219miles
Real World Estimate: 186miles
Battery Size: 52kWh

Options

Standard Equipment

Technical Data

10" digital instrumental cluster
Connected services
Driver attention alert level-4 with driver monitoring camera
Electronic power steering (EPS)
External temperature sensor
Intelligent speed assistance speed limit information
Lane keep assist
Multi-function on-board trip computer
Reverse parking sensors
Telematic box module with e-call
TPMS (Tyre pressure monitoring system)

Uconnect Infotainment system with Nav, 10" colour touchscreen, WiFi mirroring, AM/FM/DAB digital radio, Bluetooth, 2 USB, 2 speakers and 2 tweeters

180 degree opening asymmetrical solid panel rear doors
Automatic headlight control
Black front bumper
Body colour rear bumper
Body colour side sliding door rail cover
Eco LED headlamps
Electric adjustable/heated door mirrors
Electrically operated front windows with one touch facility
High beam assist
High level third brake light
Integrated daytime running lights
Painted decor strips (Side mouldings)
Painted door handles
Painted exterior mirrors
Rain sensitive windscreen wipers
Short Antenna
Visible VIN at windscreen base

6 fixed floor mounted load restraint tie bracket points
6 way reach, rake, height and lumbar adjust comfort driver seat
AT shifting by e-Toggle
Audio Controls steering wheel buttons
Carpeted floor in cabin
Chrome air vents
Chrome interior door handle
Closed upper and open lower glove boxes
Dashboard storage areas
Double passenger bench seat with centre multi-purpose seat (shelf, seat, armrest, storage)
Driver seat armrest and adjustable headrest
Front door pockets with 1.5L bottle holder
Hard plastic floor protection in load area
Load through bulkhead
Mica cloth upholstery
Mistral black dashboard
Overhead storage shelf in cabin
Reach and rake adjustable steering column

Dynamic surround view pack with electric folding door mirrors - Doblo

3x3 point seatbelts in 1st row
Acoustic vehicle alerting system
Automatic activation of hazard warning lights on major deceleration
Automatic door unlocking in event of accident
Curtain airbags
Door opening warning and audible lights on warning
Driver's airbag
Front passenger airbag
Outer front seats with height adjustable seatbelts + pretensioners
Seatbelt unfastened audible warning and warning light
Side airbags

Dashboard mounted central locking push button and auto locking above 7mph
Deadlocking for passenger and cargo area
Perimeter and volumetric thatcham category 1 approved alarm with tilt sensor
Remote control central locking and deadlocking
Rolling code transponder immobiliser
Selective cabin and cargo area locking via 3-button plip remote control key (x2)

12v socket in dashboard
ABS
Advanced emergency braking system (AEBS)
Electronic brake force distribution
Electronic Stability Control (ESC)
Hill start assist

205/60 R16 96H XL Class A+ tyres

Battery Capacity % guaranteed under warranty

70
Battery Capacity in kWh

52
Battery Charging Scenario 1 - Charge Time (Mins)

1350
Battery Charging Scenario 1 - Percentage Change

0-100
Battery Charging Scenario 1 - Power Supply - kW

1.8
Battery Charging Scenario 2 - Charge Time (Mins)

403
Battery Charging Scenario 2 - Percentage Change

0-100
Battery Charging Scenario 2 - Power Supply - kW

7.4
Battery Charging Scenario 3 - Charge Time (Mins)

290
Battery Charging Scenario 3 - Percentage Change

0-100
Battery Charging Scenario 3 - Power Supply - kW

11
Battery Charging Scenario 4 - Charge Time (Mins)

30
Battery Charging Scenario 4 - Percentage Change

0-80
Battery Charging Scenario 4 - Power Supply - kW

100
Battery Leased

No
Battery Type

Lithium-ion
Charging Port Location

Left Side Rear
Coupler/Connector Type

CCS Type 2
Maximum Charging Rate - kW

100
Standard manufacturers Battery warranty - Mileage

100000
Standard manufacturers Battery warranty - Years

8
Usable Battery Capacity

50.7
WLTP - EC (kWh/100km) - Comb - TEH

21.7
WLTP - EC (kWh/100km) - Comb - TEL

17.4
WLTP - EC (miles/kWh) - Comb - TEH

2.9
WLTP - EC (miles/kWh) - Comb - TEL

3.6
WLTP - Pure Electric Range (km) - City

490
WLTP - Pure Electric Range (km) - City - TEH

391
WLTP - Pure Electric Range (km) - City - TEL

490
WLTP - Pure Electric Range (km) - Comb

343
WLTP - Pure Electric Range (km) - Comb - TEH

289
WLTP - Pure Electric Range (km) - Comb - TEL

352
WLTP - Pure Electric Range (miles) - City

304
WLTP - Pure Electric Range (miles) - City - TEH

243
WLTP - Pure Electric Range (miles) - City - TEL

304
WLTP - Pure Electric Range (miles) - Comb

213
WLTP - Pure Electric Range (miles) - Comb - TEH

180
WLTP - Pure Electric Range (miles) - Comb - TEL

219

CO

Not Available
CO2

0
HC

Not Available
HC+NOx

Not Available
Noise Level dB(A)

Not Available
NOx

Not Available
Particles

Not Available
Standard Emissions

Not Available

Automatic Transmission

Yes
Bore

Not Available
Catalytic Convertor

Not Available
CC

1
Compression Ratio

Not Available
Cooling System

Not Available
Cylinder Layout

Not Available
Cylinders

Not Available
Engine Codes

Not Available
Engine Layout

Not Available
Engine Make

Not Available
Fuel Delivery

Not Available
Fuel Type

ELECTRIC
Gears

1 SPEED
Manual Transmission

No
Number of Valves

Not Available
Stroke

Not Available
Valve gear

Not Available

EC

Not Available
EC Combined

Not Available
EC Extra Urban

Not Available
EC Urban

Not Available

Alternative Fuel Qualifying

Yes
Did at least one aspect of this vehicles safety give cause for concern?

No
Badge Engine CC
Badge Power

136
Based On ID

Not Available
Battery AH

Not Available
Battery Volts

Not Available
Chassis Engine Number

Not Available
Clutch

Not Available
Coin Description

Not Available
Coin Gross Vehicle Weight Code

Not Available
Coin Power Output Code

Not Available
Coin Series

Not Available
Coin Wheelbase Description Code

Not Available
Coin Wheelbase Name Code

Not Available
Exhaust System

Not Available
Front Brakes

VENTILATED DISCS
Front Suspension

MCPHERSON STRUT
Generation Mark

3
Ghost model for valuation purposes

No
Insurance Group 1

Not Available
Insurance Group 2

Not Available
NCAP Adult Occupant Protection %

Not Available
NCAP Child Occupant Protection %

Not Available
NCAP Front/Side Impact - Discontinued February 09

Not Available
NCAP Overall Rating - Effective February 09

Not Available
NCAP Overall Rating - LCV

4 Star
NCAP Pedestrian - Discontinued February 09

Not Available
NCAP Pedestrian Protection %

Not Available
NCAP Safety Assist %

Not Available
Rear Brakes

DISCS
Rear Suspension

COIL SPRINGS
Relative Height

H1
Relative Length

L1
Running Cost League Headings

SMALL
Service Interval Frequency - Months

24
Service Interval Mileage

25000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

120000
Standard manufacturers warranty - Years

3
Steering

PAS
Timing Belt Interval Frequency - Months

Not Available
Timing Belt Interval Mileage

Not Available
Vehicle Homologation Class

N1
Vin/Frame No.

Not Available

0 to 62 mph (secs)

11.7
BHP

136
Engine Power KW

100
Engine Power RPM

5500
Engine Torque LBS.FT

199
Engine Torque MKG

27.5
Engine Torque NM

270
Engine Torque RPM

3674
Top Speed

82

Emissions Test Cycle

WLTP

Alloys?

No
Automatic Clutch

Yes
Plated 3rd Axle

Not Available
Plated 4th Axle

Not Available
Space Saver?

No
Tyre Make

Not Available
Tyre Size Front

205/60 R16
Tyre Size Rear

205/60 R16
Tyre Size Spare

TYRE REPAIR KIT
Wheel Style

Not Available
Wheel Type

16" STEEL

Front Overhang

892
Height

1796
Height (including roof rails)

Not Available
Length

4403
Load Height

1200
Load Length

1817
Load Space Width Between Wheel Arches

1229
Load Width

1527
Lower Rear Door Width

1241
Rear Door Height

1196
Rear Overhang

726
Side Load Door Height

1072
Side Load Door Width

641
Turning Circle - Kerb to Kerb

10.8
Turning Circle - Wall to Wall

11.3
Upper Rear Door Width

1087
Wheelbase

2785
Width (excluding mirrors)

1848
Width (including mirrors)

2107

Boot Capacity Saloons

Not Available
Fuel Tank Capacity (Litres)

Not Available
Gross Train Weight

3200
Gross Vehicle Weight

2450
Load Space Volume

3.3
Luggage Capacity (Seats Down)

Not Available
Luggage Capacity (Seats Up)

Not Available
Luggage Capacity - 2nd Row Seats Removed

Not Available
Luggage Capacity - 2nd Row Seats Up

Not Available
Luggage Capacity - 3rd Row Seats Down

Not Available
Luggage Capacity - 3rd Row Seats Removed

Not Available
Luggage Capacity - 3rd Row Seats Up

Not Available
Max. Towing Weight - Braked

750
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

1691
No. of Seats

3
Payload

759
Plated 2nd Axle

1400
Plated Front Axle

1200
